Component | Description |
Dimension | 657.2 (L)* 625.8 (W)* 1075.4(H)mm |
Chassis | Robust case, metal/ plastics |
Chipset | M0564SE4AE |
Display | Charge display 2*10ports, HTN LCD, 330.0x22.0mm active area,12 O'clock view angle, white display on blue base |
DC Output | 19V, 3A, 2*10ports |
PDU | 1200W AC Power delivery control |
Ext AC socket | 220V/10A 50-60HZ |
Input AC | 220V/10A 50-60HZ *1 |
Adapter | 20*19V, 3A |
Leakage Protector | 0.03A (leakage operating current ), t≤0.1s |
Over Voltage Protection (OVP) | Over 5% DC output |
Over Current Protection (OCP) | Over 3.2A DC output |
Short circuit Protection | Over 6A DC output |
Table | Wood, 657.2(L)*625.8(W)*18(H)mm |
Handle | Retractable handle, stainless steel |
Front door | 696.8(L)*544(W)mm,with lock, For devices charge |
Rear door | 876(L)*544(W)mm,with lock, For module installation |
Slots for charger Devices | 2*10 slots |
Wheel | 4* 3 inch wheel, load bearing 200(50*4)KG, Omni-directional |
Security hole | Metal hole lock for charger security |
Weight | About 50kg |
Environment Temperature | 0~50 °C |
Certification | S-mark |
