Component | Description |
Dimension | 560.5 (L)* 584.0 (W)* 988.6(H)mm |
Chassis | Robust case, metal/ plastics |
Chipset | M0564SE4AE |
Display | Charge display 1*10ports, HTN LCD, 330.0x22.0mm active area, 12 O'clock view angle, white display on blue base |
USB Output | 5V, 2.4A, 1*10ports |
USB Output for Raspberry Pi | 5V, 2.4A, 1*7ports |
PSU | Input:110-220V; Output:5V,200W*1 |
Leakage Protector | 230V,5A |
Table | Wood, 532.0(L)*584.0(W)*18.0(H)mm |
Handle | Retractable handle, stainless steel |
Front door | 615.3(L)*423.8(W)mm,with lock, For devices charge,with USB Type A charge Logo |
Rear door | 804.3(L)*423.8(W)mm,with lock, For module installation |
Slots for 5V charger Devices | 10 slots for 5V tablets charge |
Slots for 5V charger Devices | 7 slots for placing Rasphberry Pi devices |
Wheel | 4* 3 inch wheel, load bearing 200(50*4)KG, Omni-directional |
Security hole | Metal hole lock for charger security |
Weight | About 44kg |
Environment Temperature | 0~50 °C |
Certification | IRAM;CB |
Component | Description |
Dimension | 560.5 (L)* 584.0 (W)* 988.6(H)mm |
Chassis | Robust case, metal/ plastics |
Chipset | M0564SE4AE |
Display | Charge display 1*10ports, HTN LCD, 330.0x22.0mm active area, 12 O'clock view angle, white display on blue base |
USB Output | 5V, 2.4A, 1*10ports |
USB Output for Raspberry Pi | 5V, 2.4A, 1*7ports |
PSU | Input:110-220V; Output:5V,200W*1 |
Leakage Protector | 230V,5A |
Table | Wood, 532.0(L)*584.0(W)*18.0(H)mm |
Handle | Retractable handle, stainless steel |
Front door | 615.3(L)*423.8(W)mm,with lock, For devices charge,with USB Type A charge Logo |
Rear door | 804.3(L)*423.8(W)mm,with lock, For module installation |
Slots for 5V charger Devices | 10 slots for 5V tablets charge |
Slots for 5V charger Devices | 7 slots for placing Rasphberry Pi devices |
Wheel | 4* 3 inch wheel, load bearing 200(50*4)KG, Omni-directional |
Security hole | Metal hole lock for charger security |
Weight | About 44kg |
Environment Temperature | 0~50 °C |
Certification | IRAM;CB |
